VOICE ALARM EN54 COMMERCIAL AUDIO

UP 8501

POWER AMPLIFIER
  • 500 W power amplifier
  • 2 inputs per channel
  • Dual AC and DC power supply
  • Priority circuit
EN 54
Where to buy
Features Specifications Related products Downloads
Where to buy
Features
  • 500 W power amplifier
  • 2 inputs per channel
  • Dual AC and DC power supply
  • Priority circuit
  • No output lines tranformers
  • Status LEDs on front panel

The UP 8500 series power amplifiers are designed with an innovative RCF power supply and amplification technology. The full digital technology allows merging extremely high efficiency both with AC and DC power supply, pro audio quality reproduction and compactness. All UP 8500 series power amplifiers are certified according to EN 54-16 standard in combination with DXT 7000 Voice Alarm system.

Part number:

12135070
UP 8501
230V, EAN 8024530007058

12135098
UP 8501
115V, EAN 8024530010867

Specifications
Amplifier specifications
Amplifier Class
D
Output power @ 100 V
1 x 500 W @ 100 V
Frequency Response (-3dB)
40 Hz ÷ 16000 Hz
Distortion (THD+N) @ 1 kHz nominal power
<0.3 %
Input section
Total number of inputs
2
Balanced
2
Mono
1
Stereo
1
Line inputs
2
Line connectors
Euroblock
General Purpose Inputs (GPI)
3
Output section
Power output connectors
Euroblock
General Purpose Outputs (GPO)
1
Configuration and control
Configuration
DIP switch, Front panel
Priority
Yes
Protections
Cooling
Forced
Short circuit
Yes
Thermal
Yes
DC
Yes
Fuses
Yes
Power requirement
Operating voltage
220-240/115 V~ 50/60Hz
Voltage selection
Internal
DC power
Yes
DC power value
48 V
Power consumption (MAX)
800 W
Standard compliance
Safety agency
CE compliant
EN54-16 certified
Yes
CPR number
1438-CPR-0241
Physical specifications
Cabinet/Case Material
Metal
Color
Black,
Rack mounting
19", 1U
Size / Weight
Height
44 mm / 1.73 inches
Width
482 mm / 18.98 inches
Depth
375 mm / 14.76 inches
Weight
5 kg / 11.02 lbs
Shipping information
Package Height
170 mm / 6.69 inches
Package Width
575 mm / 22.64 inches
Package Depth
480 mm / 18.9 inches
Package Weight
6.9 kg / 15.21 lbs
