COMMERCIAL AUDIO

CA 2+2/C

SHIELDED BIPOLAR CABLE

Two pair bipolar cable with conductors section of 0.25 mm2.
PVC sheath colour grey RAL 7001.
Sold in 100 m coil.

Where to buy

Features

Two pair bipolar cable with conductors section of 0.25 mm2.
PVC sheath colour grey RAL 7001.
Sold in 100 m coil.

CA 2+2/C is a shielded flexible cable for data transmission, suitable for fixed installation in industrial environments.

Part number:

12399043
CA 2+2/C
EAN 8024530014544

Specifications

General specifications

Number of conductors:

Conductors section (mm2):

0.25

Overall diameter (mm):

5.50

Sheath material:

PVC

Sheath colour:

Grey RAL 7001

Insulation (V):

300 / 500

Standards:

CEI 20-29 Cl. 5
CEI 20-22 II
DIN EN 60228 Cl. 5
IEC 60332.3A

Coil length (m):

100

Standard compliance

Safety agency

CE compliant

Physical specifications

Color

Black

Size / Weight

Height

1000 mm / 39.37 inches

Diameter

6 mm / 0.24 inches

Weight

0.07 kg / 0.15 lbs

Shipping information

Package Height

100 mm / 3.94 inches

Package Width

300 mm / 11.81 inches

Package Depth

300 mm / 11.81 inches

Package Weight

0.07 kg / 0.15 lbs
