COMMERCIAL AUDIO

BM 3022

PAGING MICROPHONE
  • Up to 30 BM 3022 paging microphones can be linked in a ‘daisy-chain’
Where to buy
Features Specifications Related products Downloads
Where to buy
Features
  • Up to 30 BM 3022 paging microphones can be linked in a ‘daisy-chain’

Gooseneck microphone with hi-quality unidirectional electret capsule Direct connection to power amplifiers input through CAT5 cable Adjustable line output with RJ45 connector Switchable automatic gain control (AGC) Up to 30 BM 3022 paging microphones can be linked in a ‘daisy-chain’ Selectable mixing, interlocking or priority mode among devices When activating a microphone, the announcement can be preceded by a chime.

Part number:

14322013
BM 3022
EAN 8024530007034

Specifications
Microphone specifications
Type
Desktop paging microphone with electret capsule
Directivity
Cardioid
Sensitivity
-65 dB
Frequency Response (-3dB)
200 Hz ÷ 7 kHz
Output impedance (ohm)
130.00 ohm
Minimum load impedance (ohm)
470.00 ohm
Signal / Noise ratio @1kHz
82.00 dB
Total harmonic distortion @1 kHz
0.65 %
Console specifications
Console Type
Paging
Working with
DXT 3000
General call
Yes
Preamplified
Yes
LED indicators
Yes
Power requirement
Operating voltage
24.00V ~ Hz
Power consumption
2.80 mA
Connections
Connectors
RJ45
Functionalities
Priority
Yes
VOX facility
Yes
Chime tone generator
Yes
Smart PTT
Yes
Automatic gain control
Yes
Accessories
Cable included
Yes
Cable length (m)
5
Standard compliance
Safety agency
CE compliant
Physical specifications
Cabinet/Case Material
Plastic
Color
Grey
Size / Weight
Height
48 mm / 1.89 inches
Width
100 mm / 3.94 inches
Depth
159 mm / 6.26 inches
Weight
0.74 kg / 1.63 lbs
Shipping information
Package Height
144 mm / 5.67 inches
Package Width
329 mm / 12.95 inches
Package Depth
129 mm / 5.08 inches
Package Weight
1.18 kg / 2.6 lbs
