ARCHIVED
LIVE SOUND

ART 315-A MKIII

ACTIVE TWO-WAY SPEAKER
  • 800 Watt Peak, 400 Watt RMS bi-amplification
  • 129 dB max spl
  • 15" woofer, high power 2.5" voice coil
  • 90 x 60, Wide dispersion constant directivity horn
Support
Features Specifications Accessories Downloads
Support
Features
  • 800 Watt Peak, 400 Watt RMS bi-amplification
  • 129 dB max spl
  • 90 x 60, Wide dispersion constant directivity horn
  • 15" woofer, high power 2.5" voice coil
  • 1" HF driver, mylar dome, 1.5" voice coil

ART 315-A is the perfect speaker for live sound situations where extra vocal punch and extremely accurate high frequency response is needed. The 15” woofer delivers a very tight punchy bass and an accurate reproduction of the midrange . The high frequencies are precise and natural thanks to the compression driver with mylar dome in front of a low compression, optimised geometry, radial phase plug. Thanks to the versatility in both monitoring and playback, it represents the ideal multipurpose solution.

ARCHIVED

Part number:

13000319
ART 315-A MKIII
220-240V, EAN 8024530009366

13000320
ART 315-A MKIII
115V, EAN 8024530009373

Specifications
Acoustical specifications
Frequency Response
45 Hz ÷ 20000 Hz
Max SPL @ 1m
129 dB
Horizontal coverage angle
90°
Vertical coverage angle
60°
Transducers
Compression Driver
1.0'', 1.5'' v.c
Woofer
15'', 2.5'' v.c
Input/Output section
Input signal
bal/unbal
Input connectors
XLR
Output connectors
XLR
Input sensitivity
-2 dBu/+4 dBu
Processor section
Crossover Frequencies
1650 Hz
Protections
Thermal, RMS
Limiter
Fast Limiter
Controls
Volume, EQ Settings
Power section
Total Power
800 W Peak, 400 W RMS
High frequencies
200 W Peak, 100 W RMS
Low frequencies
600 W Peak, 300 W RMS
Cooling
Convection
Connections
VDE
Standard compliance
Safety agency
CE compliant
Physical specifications
Cabinet/Case Material
PP Composite
Hardware
4 x M10 Flying p.
Handles
2 side, 1 top
Pole mount/Cap
Yes
Color
Black
Size / Weight
Height
680 mm / 26.77 inches
Width
405 mm / 15.94 inches
Depth
345 mm / 13.58 inches
Weight
17 kg / 37.48 lbs
Shipping information
Package Height
798 mm / 31.42 inches
Package Width
466 mm / 18.35 inches
Package Depth
406 mm / 15.98 inches
Package Weight
20.4 kg / 44.97 lbs
Accessories
Downloads
MANUALS
USER MANUAL
PDF
591 KB
14-01-2020
SPECIFICATIONS
SPECSHEET - ENG
PDF
1 MB
18-10-2024
SOFTWARE
GLL
ZIP
684 KB
08-03-2018
