Merkmale
  • 80W RMS power handling
  • 114 dB max SPL
  • 70 ÷ 20000 Hz frequency range
  • 130° constant directivity conical coverage angle
  • 6.5" high power woofer
  • 1" neodymium dome tweeter
  • Self extinguishing plastic body
  • Steel magnetic front grille
  • 4 pole EUROBLOCK connector (audio input and parallel link output)
  • 5 m hanging cable included

PMR 60T is a two-way pendant monitor speaker, suitable for a wide range of applications. Thanks to its elegant and discreet design and refined finishes, it is suitable for all environmental and architectural conditions. Featuring a 6.5’’ woofer and 80 W RMS power, it is also equipped with a transformer for connection to constant voltage lines (70/100 V). The high quality of its transducers (arranged in a coaxial configuration) guarantees faithful and precise musical reproduction throughout the audio spectrum and allows to reach truly remarkable sound pressure levels for such compact products. The connection is simple and safe thanks to the removable four-pole screw terminals. The front grille is fixed by magnets and can therefore be easily removed to access the power rotary switch.


NEW

Part number:

13100098
PMR 60T W
White - RAL 9003, EAN 8024530020606

13100100
PMR 60T B
Black - RAL 9005, EAN 8024530020590

Spezifikationen
Spezifikation
Frequenzgang (-10dB)
70 Hz ÷ 20000 Hz
Max SPL @ 1m:
114 dB
Abdeckungswinkel:
130°
System-Empfindlichkeit
89 dB
Power sektion
Amplification
Full Range
Nominalimpedanz
8 ohm
Leistungsaufnahme
80 W RMS
Paek Power
320 W PEAK
Übergangsfrequenz
2500 Hz
Schallwandler
Dome Tweeter
1 x 1.0'' neo, 1.0'' v.c
Woofer
1 x 6.5'', 1.2'' v.c
Input/Output sektion
Eingangsbuchsen
Euroblock
Ausgangsanschlüsse
Euroblock
Transformator mit Konstantspannung
70/100 V
Auswahl der Leistung 1
80 W - 125 ohm
Auswahl der Leistung 2
40 W - 250 ohm
Auswahl der Leistung 3
20 W - 500 ohm
Auswahl der Leistung 4
10 W - 1000 ohm
Auswahl der Leistung 5
5 W - 2000 ohm
Standardkonformität
Safety agency
CE compliant
Physikalische daten
Gehäuse Material
ABS
Gitter
Steel
Farbe
White - RAL 9003, Black - RAL 9005
Größe / Gewicht
Höhe
236 mm / 9.29 inches
Durchmesser
300 mm / 11.81 inches
Gewicht
5.1 kg / 11.24 lbs
Versandinformationen
Verpackung Höhe
340 mm / 13.39 inches
Verpackung Breite
362 mm / 14.25 inches
Verpackung Tiefe
362 mm / 14.25 inches
Verpackungsgewicht
6.5 kg / 14.33 lbs
Downloads
HANDBÜCHER
PDF
1,1 MB
10-03-2023
DATENBLÄTTER
PDF
402 KB
20-03-2025
PDF
404 KB
20-03-2025
ZEICHNUNGEN
DXF
1,4 MB
20-06-2024
PDF
222 KB
20-06-2024
PDF
538 KB
20-06-2024
